Interface

Table 5.25 Format of SCT STATUS Response (1/2)

BYTE Contents

000h
001h

Format Version

002h

003h

SCT Version

004h

005h

SCT Spec

006h

007h

008h

009h

Status Flag

Bit31-1: Reserved

Bit0: Initialized flag (maintained Power-OFF/ON)

0 = When any user LBA is written, this bit is cleared.

This bit is also cleared if the capacity of the drive is changed via
SET MAX (EXT), DCO.

1= A WRITE SAME command to all logical blocks has completed

without error.

00Ah

Drive State

00h = Active

01h = not support (Standby)

02h = not support (Sleep)

03h = DST executing in background.

04h = SMART Off-line Data collection executing in background.

05h = SCT command executing in background.

06h-FFh = Reserved

00Bh

to

00Dh

Reserved

00Eh

00Fh

Extended Status Code

Status of last SCT command issued.

* (See Table 5.26)

010h

011h

Action Code

Action code of last SCT command issued.

012h

013h

Function Code

Function code of last SCT command issued.

5-74

C141-E249
