Interface

Table 5.27 Action code

Code

Function

Data transfer

-

0001h Not

supported

-

0002h

WRITE SAME
See Table 5.28.

Write

0003h

ERROR RECOVERY CONTROL
See Table 5.29.

-

0004h

FEATURE CONTROL
See Table 5.30.

-

0005h

SCT DATA TABLE
See Table 5.31.

Read

Reserved -

C000h

to

FFFFh

Vender Specific

0000h Reserved

0006h

to

BFFFh

-


Table 5.28 WRITE SAME (1/2)

Byte Name Value

Description

000h
001h

Action Code

0002h

WRITE SAME

0001h

Repeat Write Pattern
It initializes it by data pattern of 32bit specified with
byte 014h-017h.

0002h

Repeat Write data block

It initializes it by data pattern of 1sct transfer by the
SCT Write data.

Repeat Write Pattern Foreground

002h

003h

Function Code

0102h

Repeat Write data block Foreground

004h

to

00Bh

LBA

(8 byte) Start LBA

0101h

5-78

C141-E249
