5.3 Host Commands

*10 Word 64: Advance PIO transfer mode support status

Bits 15-8: Reserved

Bits 7-0: Advance PIO transfer mode

Bit 1:

'1' = Mode 4 supported

Bit 0:

'1' = Mode 3 supported

*11 WORD 75: X ' 001F ' (32)

*12 WORD 76

Bits 15-11: Reserved

Bit 10:

'1' = Supports the PHY event counter.

Bit 9:

'1' = Supports the Power Management initiation request from

the host system.

Bit 8:

'1' = Supports the Native command queueing.

Bits 7-4: Reserved

Bit 3:

Reserved for SATA

Bit 2:

'1' = Supports the Gen-2 signaling speed.

Bit 1:

'1' = Supports the Gen-1 signaling speed (1.5Gbps)

Bit 0: Reserved

C141-E249

5-111
