5.3 Host Commands

Error reporting conditions

(1) The device is in Set Max Locked mode or Set Max Freeze Locked mode

(ST = 51h, ER =04h).

(2) A SATA communication error occurred (ST = 51h, ER = 14h).

At command issuance (Shadow Block Registers setting contents)

CM

1 1 1 1 1 0 0 1

x x x x

xx

CH

CL

SN

SC

FR

xx

xx

xx

xx

01

DH


At command completion (Shadow Block Registers contents to be read)

ST Status

information

DH

CH

CL

SC

SN

ER

xx

xx

xx

xx

xx

Error information


Password information

Words Contents

0 Reserved

1 to 16

Password (32 bytes)

17 to 255

Reserved

C141-E249

5-139
