I N S T A L L A T I O N
3
Remove the gears and spools from the ends of the cardboard cores.
Black Spool
Blue Gear
White Gear
4
Install the gears and spools into the cardboard cores of the new
ribbon. Pay special attention to the position of the ribbon as shown in
the illustration.
Black Spool
New Ribbon
Blue Gear
White Gear
