5-27
X4
X5
T4
T5
X12
T12
X13
T13
When connecting multiple emergency stop switches in
series
X16
X17
24V DC
When not using the start switch
（
Auto start）
X16
X17
24V DC
When not detecting the welding of start
switch
（
Manual start）
X16
X17
24V DC
When detecting the welding of start
switch
（
Control start）
S7
S7
X0
X1
T0
T1
X2
T2
X3
T3
When not using some safety inputs
24V DC
X4
X5
T4
T5
X12
T12
X13
T13
NOTE: Applicable safety performance is dependent
upon each system configuration.
Note: When using a spring lock type safety switch for a safety input of the SafetyOne, if the solenoid
output of SafetyOne is connected to the solenoid power terminal of the safety switch directly, then the
start condition cannot be established due to the safety input staying in the OFF state. In this case,
connect the switch or other equipment to the solenoid output of SafetyOne, and use the OFF operation
of the solenoid for lock control.
