3-5

■ Installing on DIN Rails

Mount and remove SafetyOne on 35mm-wide DIN rails according to the following instructions.
Applicable DIN rail: (for example) BAA1000 (IDEC)

Mounting on DIN rail
1. Fasten DIN rail to a panel using screws.
2. With the top of SafetyOne unit facing up, as shown in Fig. 3.4, insert the groove, on the rear

of the unit, and press the unit in the direction of the arrow.

3. Use BNL6 mounting clips (sold separately) on both sides of SafetyOne to prevent it from

moving sideways.

Clamp

Fig. 3.4 Mounting

Removing from DIN Rail
1. Insert a flat screwdriver into the slot in the clamp.
2. Pull the clamp until you hear a click, as shown in Fig. 3.5.
3. Remove SafetyOne bottom out.

Fig. 3.5 Removing

35mm-wideDIN rail

Clamp
