HP Pavilion zt1100/xz100 Omnibook xt1000 Removal and Replacement 2-39
Component Removal Procedure Additional Steps
PCA, volume control Keyboard cover
(page 2-9).
Keyboard (page 2-11).
Display assembly
(page 2-18).
Top case (page 2-27).
Hinge saddle, right
(page 2-30).
Carefully lift the PCA off of its connector and out of the
notebook.
Reassembly Notes: Make sure the headphone jack
fits through its opening in the bottom case, and that
the PCA is set securely on its connector.
Saddles, hinge See page 2-30.
Socket, PCMCIA Plug-in module (page 2-5).
Hard disk drive (page 2-6).
Keyboard cover
(page 2-9).
Keyboard (page 2-11).
SDRAM modules
(page 2-13).
Mini-PCI card (page 2-16).
Display assembly
(page 2-18).
Fan and heatsink
(page 2-22).
CPU module (page 2-25).
Top case (page 2-27).
Hinge saddles
(page 2-30).
Motherboard (page 2-32).
Remove the four screws (M2x3.5) attaching the
PCMCIA socket to the motherboard, and remove the
socket.
Speaker, left Keyboard cover
(page 2-9).
Remove the retaining screw from the speaker.
Disconnect the speaker wires from the motherboard,
and lift the speaker out of the notebook.
Reassembly Notes: Make sure the tabs on the left
side of the speaker fit between the corresponding tabs
in the bottom case, and the speaker wire fits through
its notch in the bottom case.
Speaker, right Keyboard cover
(page 2-9).
Keyboard (page 2-11).
Remove the retaining screw from the speaker.
Disconnect the speaker wires from the motherboard,
and lift the speaker out of the notebook.
Reassembly Notes: Make sure the tab at the right
rear of the speaker fits under the corresponding tab in
the bottom case, and the speaker wire fits through its
notch in the bottom case.
Tray, hard disk drive See page 2-7.
