HP Pavilion zt1100/xz100 Omnibook xt1000 Removal and Replacement 2-19
Figure 2-15. Removing the Display (2)
Reassembly Notes
• While installing the hinge screws, support the display so that it remains approximately flat.
• Make sure the cable fits into its slot in the bottom case, and reinsert the cable into the retaining clip
near the left display hinge.
• Make sure the tabs on the left side of the left speaker fit between the corresponding tabs in the
bottom case, and the speaker wires fit through their notch in the bottom case.
Screw, M2×4mm
Screws,
M2×4mm (2)
