HP Pavilion zt1100/xz100 Omnibook xt1000 Removal and Replacement 2-33
5. Lift the front edge of the motherboard slightly, then carefully lift the motherboard forward and out
of the bottom case.
Figure 2-23. Removing the Motherboard
Reassembly Procedure
• When reinstalling the motherboard, see “Reinstalling the Motherboard” on page 2-34.
• When reinstalling the bottom case, see “Replacing the Bottom Case” on page 2-35.
Screws, M2×4mm (2)
Screws,
M2.5x6mm (2)
Screws,
M2.5x6mm (2)
