HP ZT1100 - Manual (Page 49)

HP Pavilion zt1100/xz100 Omnibook xt1000 Removal and Replacement 2-27
Removing the Top Case
(HP Authorized Service Providers Only)
Required Equipment
• #0 Phillips screwdriver.
Removal Procedure
1. Unplug the AC adapter, if present, and remove the battery.
2. Remove these additional assemblies:
• Plug-in module (page 2-5).
• Hard disk drive (page 2-6).
• Keyboard cover (page 2-9).
• Keyboard (page 2-11).
• Display assembly (page 2-18).
3. Remove the retaining screws from the bottom of the notebook.
4. Remove the screws from just inside the hard disk drive compartment, and just inside the plug-in
module compartment.
