Operating Instructions
153 146 89
C 9.92
Operating the attachments
Joystick operation
(proportional for sensitive operation)
Direction of joystick
Forward/back Left /right
Joystick level 0
(without button) Front lift Y0
Fwd.:
lowering
Back: lifting
Float position on membrane keyboard
Front right quick coupler X0
Float position X0 on membrane keyboard 2
Joystick level 1
(with button 1 pressed) Dumping device / rear Lift * Y1
Fwd.:
lowering
Back: lifting
Float position Y1 on membrane keyboard 1
Front right quick coupler X1
Float position Y1 on membrane keyboard 3
Joystick level 2
(with button 2 pressed) Front left quick coupler Y2
No float position intended
Rear left quick coupler X2
No float position intended
Joystick level 3
(with button 3 pressed) Front lift tilt control Y3
(included in front lift)
Fwd.:
tilt right
Back: tilt left
Lateral control of the front lift X3
Alternatively: Quick coupler
Left:
pivot left
Right: pivot right
* Selectable with 3-way cock
