Operating Instructions
153 146
139
C 9.92
Transport, hoisting, towing
ATTENTION
If the parking brake can not be released due
to a loss of electrical power or an electrical
failure, the electric cylinder must be relieved
before the tractor can be towed.
DANGER
Secure the tractor against rolling with chocks.
-
Pull off the protective hose (3) toward the front.
-
Remove the lock nut (2) with a 17mm Allen key until
the electric cylinder (1) is relieved.
The parking brake is now released and the tractor can be
towed.
Have the parking brake repaired only by your service cen-
tre.
-
Fully extend the electric cylinder.
-
Screw a new lock nut (2) on until the lock nut con-
tacts the compression spring.
-
Refit the protective hose (3).
Check the parking brake.
3
2
1
Bild_S 990_026
