C 9.92 Operating Instructions
190 153 146
Maintenance as required
Cleaning the fresh air filter and filter mat,
replacing if necessary
- Remove the fastening screws (1).
- Remove the filter cover (2) and take out the filter
element.
- Clean the filter element or replace it.
NOTE
An activated carbon filter* is available for use
with spray chemicals, etc.
- Refit the filter element and filter cover.
- Remove the fastening screws (3).
- Remove the panel (4).
- If an air conditioner is installed, pull off the sealing
tape and remove the capillary tube (6) from the
evaporator.
- Remove the filter (5).
- Clean the filter mat or replace it with a new one.
Installation is in the reverse order of removal.
* Option
Bild_S 990_039
1 2 3 4
