C 9.92
Operating Instructions
108
153 146
Operating the attachments
Operating the hydraulic system* (fixed setting 80 L)
The hydraulic system is a facility for operating attachments
with a fixed hydraulic power requirement. The hydraulic sys-
tem is operated electrically from the driver’s station.
-
Connect the hydraulic hoses of the attachment to the
screw couplings (1) and (2) and the leakage oil cou-
pling (3).
ATTENTION
Turn on the safety switch only at low engine
speed.
-
Release the lock on the safety switch (4) and depress
the switch. The indicator in the switch will light.
ATTENTION
Increase the speed of the engine slowly.
-
The attachment will be supplied with an oil flow of
approx. 80 L/min at the rated RPM.
Bild_S 990_021
1
2
3
Bild_S 990_022
4
