3. Lift the media load lever (1).
4. Use the white rewind switch on the media feed side of the printer to rewind the media back onto the
main scroller.
5. Remove the main scroller from the printer and place it on a suitable table.
6. Loosen the knob (3) and remove the flange stopper (2) and the flange spacer (1) from the main scroller.
7. Remove the scroller from the media roll.
a. Rotate the hand wheel counterclockwise (1).
b. When a gap is visible between the hand wheel and the main scroller shaft, remove the main
scroller from the media roll.
ENWW Remove a media roll from the printer 67
