HP 10000s - Manual (Page 67)

22. If you are using vinyl chloride (PVC) media (1), do not use the full tension bar as explained previously.
Instead, adjust the tension bar (2) length to approximately half the width of the media and position it
in the slack area without the flanges.
NOTE If you are using vinyl chloride (PVC) media, it is recommended to use media tube
flanges in order to prevent weaving. Refer to Use media tube flanges
Use the media edge guards
Set the media edge guards (1) on the right and left of the media in the printing path to reduce the risk of
printhead crashes.
NOTE When using the media edge guards, the right and left margins increase from 5 mm to 10
mm.
If you need to activate or deactivate the use of the media edge guards, you can do it through the front panel
by accessing the MEDIA REG menu:
1. Press the Online key.
ENWW Use the media edge guards 57
