IPv6 Access Control Lists (ACLs)
Planning an ACL Application
How an ACE Uses a Prefix To Screen Packets for
SA and DA Matches
For an IPv6 ACL, a match with a packet occurs when both the protocol and
the SA/DA configured in a given ACE within the ACL are a match with the
same criteria in a packet being filtered by the ACL.
In IPv6 ACEs, prefixes define how many leading bits in the SA and DA to use
for determining a match. That is, the switch uses IPv6 prefixes in CIDR format
to specify how many leading bits in a packet’s SA and DA must be an exact
match with the same bits in an ACE. The bits to the right of the prefix are
“wildcards”, and are not used to determine a match.
Prefix Range of Applicable Addresses Examples
/0 any IPv6 host ::/0
/ 1 — /127 all IPv6 hosts within the range defined by 2001:db8::/48
the number of bits in the prefix
2001:db8::/64
/128 one IPv6 host 2001:db8::218:71ff:fec4:2f00/128
For example, the following ACE applies to Telnet packets from a source
address where the leading bits are set to 2001:db8:10:1 and any destination
address where the leading bits are set to 2001:db8:10:1:218:71ff:fec.
permit tcp 2001:db8:10:1::/64 eq 23 2001:db8:10:1:218:71ff:fec4::/112
Prefix Defining the Mask
for the Leading Bits in the
Prefix Defining the Mask
for the Leading Bits in the
Source Address Destination Address
Figure 8-6. Example of SA/DA Prefix Lengths
Thus, in the above example, if an IPv6 telnet packet has an SA match with the
ACE’s leftmost 64 bits and a DA match with the ACE’s leftmost 112 bits, then
there is a match and the packet is permitted. In this case, the source and
destination addresses allowed are:
Address Prefix Range of Unicast Addresses
Source (SA) 2001:db8:10:1 < prefix >::0
to
< prefix >:FFFF:FFFF:FFFF:FFFF
Destination (DA) 2001:db8:10:1:218:71ff:fec4 < prefix >:0
to
< prefix >:FFFF
8-32
