Local Port Operation

HP IP Console Switch User Guide

6-15

HP CONFIDENTIAL

Writer: Amy L. Laffitte File Name: g-ch6 Local Port Operation.doc

Codename: Eagle Part Number: 263924-002 Last Saved On: 3/31/03 3:17 PM

Changing the Display Behavior

From the Menu dialog box, the display order of servers, switch connection mode,
and a time to delay display of the OSD after pressing the Print Scrn key can be
changed. The display order setting alters how servers display in several screens,
including the Main, Devices, and Broadcast dialog boxes.

Accessing the Menu Dialog Box

To access the Menu dialog box:

1. Press the Print Scrn key. The Main dialog box is displayed.

2. Click Setup. The Setup dialog box is displayed.

3. Click Menu. The Menu dialog box is displayed.

Figure 6-7: Menu dialog box
