Installing the IP Console Switch
2-8 HP IP Console Switch User Guide
HP CONFIDENTIAL
Writer: Amy L. Laffitte File Name: c-ch2 Installing.doc
Codename: Eagle Part Number: 263924-002 Last Saved On: 3/31/03 3:13 PM
Using Rear Rack Installation
IMPORTANT: If you are installing a console switch with a 1U component, such as the 1U
Keyboard Drawer Rack Option Kit, additional rack space is not required, making it a
0U installation.
To install the IP Console Switch in the rear of the rack:
1. Attach the slide rail brackets to the console switch, using two screws on
each slide.
1
2 3
4 5
6 7
8 9
10 11
12 13
14 15
16
100-240V , 1.0A, 50 /60 Hz
T 2A, 250 VAC C AUTION: For continued protection against risk of fire, replace only with same type and rating of fuse.
Figure 2-6: Attaching the slide rail brackets
