Viewing the Status of your IP Console Switch System
The status of the servers in your system is indicated in the right column of the
Main dialog box.
Table 6-1: OSD Status Symbols
Item Description
(green circle) Interface Adapter is connected or powered on.
Interface Adapter is not connected or is powered off.
Interface Adapter is tiered to another console switch and is not
connected or is powered off.
Interface Adapter is tiered to another console switch and is
connected or powered on.
(yellow circle) Interface Adapter is being upgraded.
A symbol that identifies which console switch is being used.
