Upgrading Firmware using TFTP

HP IP Console Switch User Guide

7-19

HP CONFIDENTIAL

Writer: Amy L. Laffitte File Name: h-ch7 TFTP Downloads.doc

Codename: Eagle Part Number: 263924-002 Last Saved On: 3/31/03 3:11 PM

Upgrading Interface Adapter Firmware

CAUTION: If a local port user has access to a specific Interface Adapter, a remote
user can obstruct the local port user’s access by performing an Interface Adapter
firmware upgrade.

To upgrade Interface Adapter firmware simultaneously:

1. Press the Print Scrn key. The Main dialog box is displayed.

2. Click Commands. The Commands dialog box is displayed.

3. Click IA Status. The IA Status dialog box is displayed.

Figure 7-9: IA Status dialog box
