Installing the IP Console Switch

2-16

HP IP Console Switch User Guide

HP CONFIDENTIAL

Writer: Amy L. Laffitte File Name: c-ch2 Installing.doc

Codename: Eagle Part Number: 263924-002 Last Saved On: 3/31/03 3:13 PM

f. Select Option F (Hardware Flow Control).

Be sure that the Change which setting? menu is configured as follows:

A—Serial Device: /dev/ttyS0

B—Lockfile Location: /var/lock

C—Callin Program:

D—Callout Program:

E—Bps/Par/Bits: 9600 8N1

F—Hardware Flow Control: No

G—Software Flow Control: No

g. Press the Enter key to return to the Configuration menu. Scroll down to the

Save setup as dfl option, and press the Enter key.

h. Scroll down the Configuration menu to the Exit from Minicom option, and

press the Enter key.
