HP IP Console Switch User Guide 3-1
HP CONFIDENTIAL
Writer: Amy L. Laffitte File Name: d-ch3 Expansion Module.doc
Codename: Eagle Part Number: 263924-002 Last Saved On: 3/18/03 10:13 AM
3
Expansion Module
An optional Expansion Module can be added to the IP Console Switch system,
enabling access for up to 8 servers on each port, increasing the total number of
accessible servers to 128.
Features
The features of the Expansion Module include:
• Connection to an IP Console Switch through a single UTP CAT5 cable
• Connection to each Interface Adapter through a single UTP CAT5 cable
• Connections for eight Interface Adapters
• An active KVM connection between one IP Console Switch port and one
Interface Adapter at a time
• No external power required
• Ability to mount along the sides or along the rear of standard 19-inch internal
mounting rails
