Local Port Operation
6-6 HP IP Console Switch User Guide
HP CONFIDENTIAL
Writer: Amy L. Laffitte File Name: g-ch6 Local Port Operation.doc
Codename: Eagle Part Number: 263924-002 Last Saved On: 3/31/03 3:17 PM
Using Basic OSD Navigation
The following table describes the keyboard and mouse OSD navigation keys.
Table 6-2: OSD Navigation Keys
Keystroke Function
Print Scrn Opens the OSD. Press the
Print Scrn key twice to send the
Print Scrn keystroke to the
currently selected device.
F1 Opens the Help screen for the
current dialog box.
Esc Closes the current dialog box
without saving changes and returns
to the previous dialog box. In the
Main dialog box, it closes the OSD
and returns to the selected server.
In a message box, it closes the pop-
up box and returns to the current
dialog box.
Alt When used in combination with the
other keys, opens dialog boxes,
selects options, and executes
actions.
Alt + X Closes the current dialog box and
returns to the previous dialog box.
Alt + 0 Selects the OK button and returns
to the previous dialog box.
Enter Completes the console switch
operation in the Main dialog box
and exits the OSD.
Single-Click, Enter In a text box, selects the text for
editing and enables the left and right
arrow keys to move the cursor.
Press the Enter key again to quit
Edit mode.
continued
