Installing the Expansion Module into the IP Console
Switch System
To install an optional Expansion Module into the IP Console Switch system:
1. Mount the Expansion Module into the rack, using one of the previously described
methods.
2. Locate up to nine UTP CAT5 cables.
3. Connect one end of a UTP CAT5 cable to the desired port on the rear panel of
the IP Console Switch.
4. Attach the other end of the UTP CAT5 cable to the IN port on the Expansion
Module.
5. Connect one end of another UTP CAT5 cable to the OUT port on the
Expansion Module.
6. Attach the other end of the second UTP CAT5 cable to the Interface Adapter.
7. Repeat steps 5 through 6 to connect any other servers.
