Model OFG- 391
Figure &
Item No. Part No. Description Qty.
3-18 COUNTERWEIGHT AND PULLEY SYSTEM
(SN: BT0802002 & BELOW)
1 52475 PULLEY ASSY ............................................................................... 1
2 51677 . PULLEY PLATE .......................................................................... 1
3 35962 . BRACKET/WHEEL ASSY .......................................................... 2
√√√√√
4 35207 . CABLE ........................................................................................ 2
5 SC01-022 . SCREW 1/4-20 X 3/4 HEX HD C ................................................. 8
6 NS02-002 . NUT KEPS 1/4-20 C .................................................................... 12
7 WA01-002 WASHER ...................................................................................... 2
8 51590 SPACER ........................................................................................ 2
9 SC01-104 BOLT ............................................................................................. 2
10 SC01-022 BOLT ............................................................................................. 2
11 51591 I BEAM – PULLEY BRACE .......................................................... 1
12 54494 ASSY – LID ARM/U-CHANNEL .................................................. 1
13 51692 . MACHINED – ARM – LID LIFT ................................................ 1
14 55883 . SCREW 3/8–16 X 1-1/2 FT HH G ................................................ 4
15 55598 . TORQUE PLATE – U-CHANNEL ............................................... 1
16 54493 . ASSY – LIFT U-CHANNEL ........................................................ 1
17 51549 . . LIFT U-CHANNEL ................................................................... 1
18 66715 . . WHEEL – TRUCK .................................................................... 4
19 51593 . . SPINDLE – U CHANNEL WHEEL ............................................ 4
20 LW01-001 . . LOCKWASHER SPLIT RING 3/8 ID ......................................... 4
21 SC01-081 . . SCREW 3/8-24 X 3/4 HEX HD S ............................................... 4
22 55873 STABILIZER COMPONENTS – ASSY .......................................... 1
23 59113 . SUPPORT ARM – STABILIZER ................................................. 2
24 51553 . ASSY – CABLE MOUNTING BRACKET ................................... 2
25 59112 . SLIDE – STABILIZER ................................................................ 2
26 59111 . BRACE – STABILIZER .............................................................. 2
27 SC01-226 . 5/16-18 X 1-1/4 FHD CAP SCREW ............................................. 6
28 SC01-146 . SCREW 1/4-20 X 3/4 HEX HD C ................................................. 2
29 NS02-002 . NUT KEPS 1/4-20 C .................................................................... 4
30 NS01-012 . NUT HEX 1/4-20 C ...................................................................... 2
31 SC01-232 . 1/4-20 X 2.00 TRUSS HD PH ZI .................................................. 2
32 54492 ASSY – CARRIAGE, WEIGHT ..................................................... 1
33 52118 . ASSY – WEIGHT BRACKET, STUD .......................................... 1
34 62018 . GUIDE – COUNTER WEIGHT .................................................... 2
35 NS02-002 . NUT KEPS 1/4-20 C .................................................................... 4
36 36627 COUNTERWEIGHT BAR .............................................................. 4
√ √ √ √ √ recommended parts
1209 3-32
