Model OFG- 391
Figure &
Item No. Part No. Description Qty.
3-15 FLUE ASSEMBLY AND BLOWER
(SN: BT0802002 & BELOW)
1 55681 FLUE ASSY – WELDMENT ............................................. 1
2 55783 BRACKET – FLUE RETAINING ..................................... 1
3 SC03-005 SCREW SD #8 X 1/2 PH PHD .......................................... 2
√√√√√
4 14420 120V BLOWER – FLUE EXHAUST W/INSULATION .. 1
√√√√√
4 14421 100V BLOWER – FLUE EXHAUST W/INSULATION .. 1
√√√√√
4 14422 240V BLOWER – FLUE EXHAUST W/INSULATION .. 1
5 21329 . INSULATION – BLOWER ............................................ 1
6 55673 STUD ASSY – BLOWER MOUNT PLATE ..................... 1
7 NS02-002 NUT KEPS 1/4-20 C ........................................................... 4
8 SC02-041 #8-32 X 7/16 PH IND XTRNL TRX .................................. 2
9 55675 ASSY – INSUL/BLOWER INLET-NAT GAS ONLY ...... 1
10 52103 DILUTION HOSE/BLOWER-NAT GAS ONLY ............. 1
11 MS01-429 HOSE CLAMP – 3 9/16-4 1/2 PL-NAT GAS ONLY ........ 2
12 32743 DILUTION HOSE ASSEMBLY-LP GAS ONLY .............. 1
13* 14384 KIT, FLUE DUCTS – BUTANE ....................................... 1
14* 54905 DILUTION BOX COVER - CE (0-3,999 FT) ................... 1
14* 55880 DILUTION BOX COVER - LP-CE (OVER 3,999 FT) .... 1
14* 55881 DILUTION BOX COVER - NAT.-CE (OVER 3,999 FT) 1
√ √ √ √ √ recommended parts
*not shown
1209 3-24
