Model OFG- 391
Figure &
Item No. Part No. Description Qty.
3-7 DRAIN PAN AND FILTER ASSEMBLY
1 52194 CRUMB CATCHER (OPTIONAL) ......................................... 1
2 03204 CRUMB CATCHER BASKET W/HANDLE (OPTIONAL) .... 1
2 21010 . CRUMB CATCHER BASKET ASSEMBLY ......................... 1
2 24429 . HANDLE - CRUMB BASKET ............................................. 1
3 52496 FILTER DRAIN PAN ASSEMBLY .......................................... 1
4 52487 . CASTER .............................................................................. 2
5 SC01-009 . SCREW 1/4-20 X 1/2 ............................................................ 8
6 NS02-002 . NUT 1/4-20 .......................................................................... 8
7 17505 FILTER CLIPS ........................................................................ 2
8 17503(use 14671) BOTTOM FILTER SCREEN (SN: KH031JJ AND BELOW) .... 1
8 17503(use 14674) BOTTOM FILTER SCREEN (SN: KH032JJ TO BT0504001) ... 1
8 65447 BOTTOM FILTER SCREEN (SN: BT0504001 AND ABOVE) .. 1
9 17502(use 14671) TOP FILTER SCREEN (SN: KH031JJ AND BELOW) ............. 1
9 17502(use 14674) TOP FILTER SCREEN (SN: KH032JJ AND ABOVE) .............. 1
10 36305 WASHER & STANDPIPE ...................................................... 1
11 55876 STANDPIPE ASSEMBLY (S/N KH031JJ & BELOW) ............. 1
11 62081 STANDPIPE ASSEMBLY (S/N KH032JJ to AH085JB) ........... 1
11 24212 STANDPIPE ASSEMBLY (S/N AH086JB to BT0504001) ....... 1
11 14658 STANDPIPE ASSEMBLY (S/N BT0504001 & ABOVE) .......... 1
√√√√√
12 USE 69289 . UNION - MALE FITTING ................................................... 1
√√√√√
13 USE 69289 . UNION - HANDLE FITTING ............................................... 1
14 24211 . WELDMENT, FILTER TUBE AND WASHER ..................... 1
15 23740 . HANDLE, STANDPIPE 8 HEAD ......................................... 1
16 SC01-245 . SCREW 10-32 X 1/2 ........................................................... 3
17 23804 . INSERT, FILTER NUT .......................................................... 1
18 OR01-007 . O-RING, FILTER NUT INSERT ............................................ 1
19 55877 . FILTER NUT (S/N KH031JJ & LOWER) .............................. 1
19 65208 . FILTER NUT (S/N KH032JJ to AH085JB) ............................ 1
19 23803 . FILTER NUT (S/N AH086JB to BT0504001) ........................ 1
19 66535 . FILTER NUT - SS (SN: BT0504001 AND ABOVE) ............... 1
20 62082 FILTER DRAIN PAN COVER ASSEMBLY ............................. 1
√√√√√
21 12102 FILTER ENVELOPE PAPER (100 PER CARTON) ................... 1
22 52209 ROD - CLEAN OUT ............................................................... 1
√√√√√
23 52208 BRUSH ................................................................................... 1
24 35310 STIRRER ................................................................................ 1
√√√√√
25 12126 BLACK L-BRUSH .................................................................. 1
26 65211 CRUMB CATCHER - SS ........................................................ 1
106 3-10
√√√√√ recommended parts
