Model OFG- 391
2-8. LID COUNTERWEIGHT The Lid Counterweight in the back of the fryer balances the
CABLES weight of the lid system to allow easier opening and closing of
the lid. The weight has two cables attached to it, and weighs
about 100 lbs. (45.4 Kg).
1. Using a Phillips head screwdriver, remove the screws securing
the back and top shrouds of the fryer and remove the shrouds.
2. Raise the lid.
3. Remove the screws securing the shroud to the frame and remove
the shroud.
4. Remove the nut from the nylatron slide and flip loosened end up
over the lid.
5. Remove the 4 keps nuts from the bracket at top of the shroud.
6. Place support under lid arm (ex: block of wood), and remove the
weights from the frame in the back of the fryer.
7. Remove the Allen head bolts securing the stabilizer bracket and
remove the bracket.
2-7 305
