Model OFG- 391
106 3-12
Figure &
Item No. Part No. Description Qty.
3-8A FILTER PUMP ASSEMBLY (SN: LH015JC and below)
1 18107 CONDUIT CONNECTOR 3/8 X 90 ................................................ 2
2 54484 BLOWER/PUMP – FLEXIBLE CONDUIT ..................................... 1
√√√√√
3 17476 PUMP SEAL KIT .......................................................................... 1
4 18105 ANTI SHORT 3/8 INCH ................................................................ 2
5 18644 CONDUIT CONNECTOR 3/8 X 90 ................................................ 2
6 51831 PUMP CONDUIT BRACKET ........................................................ 2
7 55757 ASSY – OIL RETURN LINE .......................................................... 1
8 16808 SLEEVE, FITTING .................................................................. 2
9 16809 NUT, FITTING ....................................................................... 2
10 17407 CONNECTOR, 1/2 MALE ELBOW ............................................... 2
11 24225 TUBE ASSY – DISCON. TO PUMP .............................................. 1
12 66676 ASSY - TUBING, DISCONNECT TO PUMP ........................... 1
13 16809 NUT, FITTING ....................................................................... 1
14 16808 SLEEVE, FITTING .................................................................. 1
√√√√√
15 17430(use 69289) UNION, MALE FITTING ....................................................... 1
√√√√√
16 67583 MOTOR – 1/2 HP FILTER PUMP .................................................. 1
17 62050 NIPPLE 1/4 NPT X 2.0 ................................................................... 1
√√√√√
18 52125 AIR-SOLENOID VALVE 120V ....................................................... 1
√√√√√
18 54908 AIR-SOLENOID VALVE 240V ....................................................... 1
19 FP02-024 NIPPLE 3/8 CLOSE ........................................................................ 1
20 16807 FITTING, CONNECTOR, MALE .................................................... 1
21 54486 AIR VALVE – FLEXIBLE CONDUIT ............................................. 1
22 FP01-122 REDUCER 3/8 TO 1/2 .................................................................... 1
23 35472 CHECK VALVE – PRESSURE ........................................................ 1
24 FP02-007 NIPPLE 3/8 X 1-1/2 ........................................................................ 1
25 17437 PUMP SUBASSY 5 GPM .............................................................. 1
√√√√√
26 17447 ROTOR - PUMP ..................................................................... 1
√√√√√
27 17446 ROLLER - TEFLON SET ......................................................... 1
√√√√√
28 17453 PUMP O RING GASKET ........................................................ 1
√√√√√
29 SC01-132 1/4-20 X 5/8 SOC HD CAP SCREW ........................................ 4
√√√√√
30 17454 BODY - PUMP ........................................................................ 1
√√√√√
31 17456 PUMP SHIELD ....................................................................... 2
√√√√√
32 17451 COVER - PUMP ...................................................................... 1
√√√√√
33 SC01-016 PLUG 1/4 HEX COUNTERSUNK ............................................ 1
√√√√√
34 SC01-026 SCREW 5/16-18 X 3/4 HEX HD C ........................................... 2
35* 85777 1/2” PUMP AND MOTOR ..................................................... 1
√√√√√ recommended parts
* not shown
