Model OFG- 391
3-19 1209
Figure &
Item No. Part No. Description Qty.
3-11 GAS PIPING AND CONTROLS
1 FP01-117 ELBOW ......................................................................................... 2
2 FP05-010 FITTING 3/8 TUBE TO 1/4 NP ...................................................... 2
3 65173 MANIFOLD TUBE ........................................................................ 1
4 65173 MANIFOLD TUBE ........................................................................ 1
5 FP01-115 NIPPLE – 3/8 to 1/2 NP. ................................................................. 2
6 FP01-112 1/2 NPT FEMALE PIPE TEE B.I. ................................................... 1
7 54875 MODULE COVER ......................................................................... 1
8 52785 BURNER SHIELD ASSY ................................................................ 2
68536 BURNER SHIELD STUD ASSY ............................................. 2
51731 STANDOFF-BURNER ........................................................... 8
9 69441 PILOT TUBE – LEFT BURNER ..................................................... 1
10 69442 PILOT TUBE – RIGHT BURNER ................................................... 1
11 FP05-011 TEE – 1/4 X 1/4 X 1/4 BR COMPR ................................................. 1
12 69442 PILOT TUBE – VALVE TO TEE ..................................................... 1
13* 21452 GAS VALVE ASSY 24V – CE – NATURAL GAS ........................... 1
13* 21453 GAS VALVE ASSY 24V – CE – LP GAS ......................................... 1
√√√√√
14 38468 . SOLENOID GAS VALVE – 24V 60 HZ – NON CE ....................... 1
√√√√√
14 34802 . SOLENOID GAS VALVE – 24V 50 HZ – CE ................................ 1
15 FP01-028 . NIPPLE, CLOSE 1/2 NPT SS 1 LG ............................................... 1
√√√√√
16 80761 . COMBINATION GAS VALVE – NAT.- (S/N: AP0907006
& ABOVE)-NON CE (USED IN 52476) ...........................................
1
√√√√√
16 80858 . COMBINATION GAS VALVE – LP.- (S/N: AP0907006
& ABOVE)NON CE .......................................................................
1
√√√√√
16 140056 KIT-GAS VALVE- NAT/LP.- (S/N: AP0907005 & BELOW)-NON CE 1
16 140042 KIT-GAS VALVE- NAT/LP.- (S/N: AP0907005 & BELOW)-NON CE
FOR UNITS BUILT WITHOUT 38468 SOLENOIDS .....................
1
√√√√√
16 21451 . 24V COMBINATION GAS VALVE – CE (USED IN 21452) .......... 1
√√√√√
16 21450 . 24V COMBINATION GAS VALVE – LP-CE (USED IN 21453) .... 1
17 52122 MAIN GAS SUPPLY LINE ASSY .................................................. 1
17 55433 MAIN GAS SUPPLY LINE ASSY - CE (before 6-14-07) ................. 1
17 76333 MAIN GAS SUPPLY LINE ASSY - CE (6-14-07 & after) ................ 1
18 59189 STUD ASSY - MODULE ENCLOSURE ......................................... 1
19 51741 WIRE COVER - GAS VALVE ......................................................... 1
20* FP01-200 FITTING - GAS INLET BSPT ........................................................ 1
√√√√√ recommended parts
*not shown
