Arrangement
Refer to the illustrations and tables below to determine the screen size and projection distance.
The values shown in the table are calculated for a full size screen: 1024×768
(a) The screen size (diagonal)
(b) Distance from the projector to the screen (±10%)
(c) The height of the screen (±10%)
Setting up
4:3
(a)
16:9
(a)
(c) up
(b)
(c) down
(a) Screen
size
[inch (m)]
4 : 3 screen
16 : 9 screen
(b) Projection distance
[m (inch)]
(c) Screen height
[cm (inch)]
(b) Projection distance
[m (inch)]
(c) Screen height
[cm (inch)]
min.
max.
down
up
min.
max.
down
up
30
(0.8)
0.9
(34)
1.1
(41)
5
(2)
41
(16)
1.0
(38)
1.1
(45)
-1
(0)
39
(15)
40
(1.0)
1.2
(46)
1.4
(56)
6
(2)
55
(22)
1.3
(50)
1.5
(61)
-2
(-1)
51
(20)
50
(1.3)
1.5
(58)
1.8
(70)
8
(3)
69
(27)
1.6
(63)
1.9
(76)
-2
(-1)
64
(25)
60
(1.5)
1.8
(70)
2.1
(84)
9
(4)
82
(32)
1.9
(76)
2.3
(91)
-2
(-1)
77
(30)
70
(1.8)
2.1
(81)
2.5
(98)
11
(4)
96
(38)
2.3
(89)
2.7 (107)
-3
(-1)
90
(35)
80
(2.0)
2.4
(93)
2.8 (112)
12
(5)
110 (43)
2.6 (102) 3.1 (122)
-3
(-1)
103 (41)
90
(2.3)
2.7 (105) 3.2 (126)
14
(5)
123 (49)
2.9 (115) 3.5 (138)
-4
(-1)
116
(46)
100 (2.5)
3.0 (117) 3.6 (140)
15
(6)
137 (54)
3.2 (127) 3.9 (153)
-4
(-2)
129 (51)
120 (3.0)
3.6 (140) 4.3 (169)
18
(7)
165 (65)
3.9 (153) 4.7 (184)
-5
(-2)
154 (61)
150 (3.8)
4.5 (176) 5.4 (211)
23
(9)
206 (81)
4.9 (192) 5.8 (230)
-6
(-2)
193 (76)
200 (5.1)
6.0 (235) 7.2 (282)
30
(12)
274 (108)
6.5 (256) 7.8 (307)
-8
(-3)
257 (101)
250 (6.4)
7.5 (294) 9.0 (353)
38
(15)
343 (135)
8.1 (320) 9.8 (384) -10
(-4)
322 (127)
300 (7.6)
9.0 (352) 10.8 (423)
46
(18)
411 (162)
9.8 (384) 11.7 (461) -12
(-5)
386 (152)
