Hitachi CP-X268AWF - Manual (Page 11)

2
About this manual. . . . . . . . . . 1
Content . . . . . . . . . . . . . . . . . . 2
Contents of package . . . . . . . 3
How to use the Slot cover lock . . . . .3
Projector features. . . . . . . . . . 4
Preparations . . . . . . . . . . . . . . 4
Fastening the lens cover . . . . . . . . . .4
Part names . . . . . . . . . . . . . . . 5
Projector . . . . . . . . . . . . . . . . . . . . . .5
Control buttons . . . . . . . . . . . . . . . . .7
Remote control . . . . . . . . . . . . . . . . .7
Setting up . . . . . . . . . . . . . . . . 8
Arrangement . . . . . . . . . . . . . . . . . . .9
Adjusting the projector's elevator . .10
Using the Security Bar . . . . . . . . . . .11
Connecting your devices . . . . . . . . .12
Connecting power supply . . . . . . . .15
Inserting an SD Card and USB Memory . .16
Remote control . . . . . . . . . . . 17
Putting batteries . . . . . . . . . . . . . . .17
Using the remote control . . . . . . . . .18
Power on/off . . . . . . . . . . . . . 19
Turning on the power . . . . . . . . . . . .19
Turning off the power . . . . . . . . . . . .19
Operating . . . . . . . . . . . . . . . 20
Adjusting the volume . . . . . . . . . . . .20
Temporarily muting the sound . . . . .20
Selecting an input signal . . . . . . . . .20
Searching an input signal . . . . . . . .21
Selecting an aspect ratio . . . . . . . . .21
Adjusting the zoom and focus . . . . .21
Using the automatic adjustment feature . .22
Adjusting the position . . . . . . . . . . .22
Correcting the keystone distortions .23
Using the magnify feature . . . . . . . .23
Freezing the screen . . . . . . . . . . . . .24
Temporarily blanking the screen . . .24
Operating the computer screen . . . .25
Multifunctional settings . . . . 26
Using the menu function . . . . . . . . .26
Content
Content
EASY Menu . . . . . . . . . . . . . . . . . . .27
Aspect, Auto keystone Execute,
Keystone, Picture mode, Brightness,
Contrast, Color, Tint, Sharpness,
Whisper, Mirror, Reset, Filter time,
Language, Go to advanced menu
PICTURE Menu . . . . . . . . . . . . . . . .29
Brightness, Contrast, Gamma,
Color temp, Color, Tint, Sharpness,
My memory
IMAGE Menu . . . . . . . . . . . . . . . . . .32
Aspect, Over scan, V. position, H. position,
H. phase, H. size, Auto adjust execute
INPUT Menu . . . . . . . . . . . . . . . . . .34
Progressive, Video NR, Color space,
Component, Video format, Frame lock,
RGB in, Resolution
SETUP Menu . . . . . . . . . . . . . . . . . .37
Auto keystone Execute, Keystone,
Whisper, Mirror, Volume, Audio
SCREEN Menu . . . . . . . . . . . . . . . .39
Language, Menu position, Blank,
Start up, MyScreen, MyScreen lock,
Message, Source name
OPTION Menu . . . . . . . . . . . . . . . . .42
Auto search, Auto keystone, Auto on,
Auto off, Lamp time, Filter time,
My button, Service, Security
MIU Menu . . . . . . . . . . . . . . . . . . . .52
Live Mode, PC-LESS Presentation,
Setup, e-SHOT, Information, Service
Maintenance . . . . . . . . . . . . . 57
Lamp . . . . . . . . . . . . . . . . . . . . . . . .57
$LU¿OWHU . . . . . . . . . . . . . . . . . . . . . .59
Replacing Internal Clock battery . . .61
Other care . . . . . . . . . . . . . . . . . . . .62
Troubleshooting . . . . . . . . . . 63
Related messages . . . . . . . . . . . . . .63
Regarding the indicator lamps . . . . .64
Phenomena that may be easy to be
mistaken for machine defects . . . . .66
Warranty and after-service. . . 69
6SHFLÀFDWLRQV . . . . . . . . . . . . 69
