6
AC inlet ( 15)
Power switch ( 19)
Elevator button ( 10)
COMPONENT
VIDEO ports (
14)
Y
C
B /P B
C R /P R
S-VIDEO port ( 14)
VIDEO port ( 14)
CONTROL port ( 13)
Elevator foot ( 10)
Rear-Left side
Ports (See below.)
Vent
AUDIO OUT port
(
13)
AUDIO IN2 port ( 13)
(In the default setting, the AUDIO
IN2 port is the audio port for
the RGB IN2 port, however, it is
possible to change the settings.
38)
AUDIO IN3 L/R port ( 14)
(In the default setting, the
AUDIO IN3 L/R port is the audio
port for the VIDEO, S-VIDEO
and COMPONENT VIDEO
ports, however it is possible to
change the settings.
38)
RGB IN2 port ( 13)
NOTE (*) About Restart switch: This projector is controlled by an internal
microprocessor. Under certain exceptional circumstances, the projector may not
operate correctly and the microprocessor will need to be reset. In such a case,
please push the Restart switch by using a cocktail stick or similar, and before
turning on again, make the projector cool down at least 10 minutes without
operating. Only push the Restart switch in these exceptional instances.
Restart switch (*) ( 66)
Part names
USB port ( 13)
C R /P R
C B /P B
AUDIO IN
2
AUDIO IN
1
RGB IN 1
RGB IN2
SD CARD
AU X I/O DC 5V 0.5A
LAN
CONTR
OL
RGB OUT
AUDIO OUT
USB
VIDEO
S-VIDEO
AC IN
Kensington lock slot
RGB OUT port ( 13)
RGB IN1 port ( 13)
AUDIO IN1 port ( 13)
(In the default setting, the AUDIO IN1 port is the audio
port for the RGB IN1 port, however, it is possible to
change the settings.
38)
SD CARD slot ( 13)
This slot is used when
utilizing SD CARD.
AUX I /O port ( 13)
This port is used when
utilizing USB Memory.
LAN port ( 13)
Used for Ethernet
input/output.
This port is used
when utilizing network
functions.
LAN
Y R
L
AUDIO IN3
AUDIO IN1
AUDIO OUT
USB
RGB OUT
AUDIO IN2
VIDEO
S-VIDEO
C B / P B
C R / P R CONTROL
RGB IN2 RGB IN1
K
AUX I/O
SD CARD
Ports
