25
2. Equipment connection and network setting
Port Settings
'LVSOD\VDQGFRQ¿JXUHVFRPPXQLFDWLRQSRUWVHWWLQJV
Click the [Apply] button to save the settings.
‡7KHQHZFRQ¿JXUDWLRQVHWWLQJVDUHDFWLYDWHGDIWHUUHVWDUWLQJWKH
network connection. The network connection must be restarted when the
FRQ¿JXUDWLRQVHWWLQJVDUHFKDQJHG7KHQHWZRUNFRQQHFWLRQFDQEHUHVWDUWHG
using [Network Restart] on the main menu.
NOTE
Item Description
Network Control Port1
(Port:23)
&RQ¿JXUHVFRPPDQGFRQWUROSRUW3RUW
Port open Click the [Enable] check box to use port 23.
Authentication
Click the [Enable] check box when authentication is required
for this port.
Network Control Port2
(Port:9715)
&RQ¿JXUHVFRPPDQGFRQWUROSRUW3RUW
Port open Click the [Enable] check box to use port 9715.
Authentication
Click the [Enable] check box when authentication is required
for this port.
SNMP Port &RQ¿JXUHVWKH6103SRUW
Port open Click the [Enable] check box to use SNMP.
Trap address &RQ¿JXUHVWKHGHVWLQDWLRQRIWKH61037UDSLQ,3IRUPDW
SMTP Port &RQ¿JXUHVWKH6073SRUW
Port open Click the [Enable] check box to use the e-mail function.
