1-6

Before powering on your system, you should become familiar with
the system unit controls.

Figure 1–1 shows the the system unit front panel controls.

System LCD

System Power Switch

System Power LED

Figure 1–1. System Unit Front Panel Controls

System Unit
Front Panel
Controls, LED,
and LCD
