Set the drawer on a flat surface.

6.

Disconnect the power distribution cable from the Fan extender
cable.

Power Extender

Power Distribution Cable

Figure B–4.Removing FAN from EMI Plate

7.

Disconnect the Fan extender cable form the SCSI PCA.
