HP 2240 User Manual
Page 209
C-26
This section describes how to connect to the system SCSI ports (nar-
row single-ended, ultra, wide–SE and fast,wide differential).
System SCSI Port Connection
The system contains two (2) SCSI connectors:
•
System Single-Ended SCSI-2 Connector
•
System Fast, Wide Differential or Ultra, Wide–SE SCSI Con-
nector
Figure C–1 shows the rear panel with terminators attached to the two
SCSI connectors. Figure C–2 shows the two SCSI connectors without
terminators. SCSI cables connect to these ports with a high-density
thumb screw connector.
Connecting to
the SCSI Ports
