CHAPTER 3
The Digital Light Menu System
DL.3 Digital Light User Manual 25
Set
Fixture
External
SVideo
NTSC_M
NTSC_MJ
PAL_B
PAL_D
PAL_G
PAL_H
PAL_I
PAL_M
PAL_N
SECAM_B
SECAM_D
SECAM_G
SECAM_H
SECAM_K
SECAM_K1
SECAM_L
SECAM_L1
Identifies the SVideo format used for video input.
Factory
Defaults On Restores factory default settings
Off Default
Lens Type
Standard
Selects the lens currently installed in the projector.
Note: these options are active for DL.3 fixtures only Long
Ultra Long
Wide
Projector
Projector
Input External
Chooses the input the Projector will accept
Internal
Projector In
by DMX Yes
Selecting Yes allows projector’s input source to be
selected from DMX
No Disables changing projector input via DMX
Projector
Lamp On Manually turns Projector Lamp on
Off Manually turns Projector Lamp off
Projector
Powerup
Always
Turns the projector lamp on whenever the fixture is
connected to power
Manual Turns on the lamp when Projector Lamp = On
DMX
Turns the projector lamp on with DMX
input (default)
Zoom
Override On
Overrides the DMX values sent by the console. Set
value manually from 0-255
Off Default
Focus
Override On
Overrides the DMX values sent by the console. Set
value manually from 0-255
Off Default
Projector
Ceiling On Rotates the image 180°
Off Default
Projector
Rear On Inverts the image for rear projection applications
Off Default
Projector OSD Menu
Clicking the Activate button accesses the Projector
Menu System’s navigation buttons
Projector Defaults
Clicking the Reset button restores Factory Projector
Defaults
Main
Tab
Sub-Tabs/
Screens
Fields
Controls
Options Function/Notes
