CHAPTER 1
Product Overview
DL.3 Digital Light User Manual 3
Content Management Application
• Available for Windows and Mac operating systems
• Communicates with other DL.3, DL.2, Axon media servers over an Ethernet network
• Uploads and downloads custom digital content to DL.3 fixtures
• Configures DL.3, DL.2 and Axon media servers
• Updates software including content, applications, and operating system to DL.3, DL.2 and
Axon media servers.
Hardware
• 17 Motion Parameters for mechanical fixture control include:
— Mechanical Iris adjustment to full black-out
— 400-degree Pan and 240-degree Tilt movement
— DMX control of projector zoom and focus
— DMX control of camera functions
• Integrated digital camera feeds digital video capture directly into the graphic engine that
provides:
— Optical + digital zoom to increase image up to 216×
— Options for 1-30 frame captures / sec
— Vertical and/or Horizontal image inversion
— Black and White, Color Negative and Freeze Frame effects
— White Balance including Red and Blue gain control
• Infrared illuminator allows video capture even in blackout settings
• Remote video input and output switching let you select live video from external source
including another DL.3 fixture’s camera feed.
• Full color display and menu functions
• Mechanical lens shift (107% vertical) to supplement software keystone correction.
• Powered by a Intel Core2 Duo 2.4 GHz processor with an ATI Radeon HD2900 Graphics Processor
and Decklink SDI Capture.
• Gigabit Ethernet for fast content uploading and multiple fixture synchronization
• Mounting system provides multiple orientation options
