CHAPTER 3
The Digital Light Menu System
24 DL.3 Digital Light User Manual
Menu Options
The menu display consists of a set of top-level tabbed screens and their associated subtabs.
Main
Tab
Sub-Tabs/
Screens
Fields
Controls
Options Function/Notes
DMX
Control
Source
DMX512 Sets DMX as fixture communication source
Art-Net
Set Universe field from 0-16 [Art-Net protocol]
Set Subnet field from 0-16 [Art-Net protocol]
Protocol
Standard Motion + global + 3 objects = 170 channels
Dual Motion + global + 2 objects = 132 channels
Single Motion + global + 1 object = 94 channels
Fixture ID 1-255
Assigns the fixture a unique number on fixture
network
Start
Channel
1-512 Sets the fixture’s DMX Start Channel
Protocol
View
Motion
Displays current fixture Movement and Camera
parameter values
Global
Displays current Intensity, Iris, Edge Fade,
Viewpoint and Keystone correction parameter
values for the composite image
Obj 1
Displays current Position, Rotation, Scaling, and
Effects parameters values for the selected graphic
object
Obj 2
Obj 3
Raw View
Main Table
Displays current DMX values for all 512 DMX link
channels in rows of values.
Offset Scrolls through rows of DMX values
Refresh
Rate
0-44 Set times/second for refreshing displayed values
Refresh
Timer On DMX values updated instantly
Off Display does not refresh
Set Fixture
Pan Invert
On Inverts the direction of the pan motor.
Off Default
Tilt Invert
On Inverts the direction of the Tilt motor.
Off Default
Pan/Tilt Swap
On Swaps Pan and Tilt directions
Off Default
Data Loss Timeout Iris
Long Closes iris after a 5 minute DMX data loss
Short Closes iris after a 5 second DMX data loss
Display
On
Default intensity
adjustment
Preview
Displays current
content preview
Off Turns off display after a period of time
Display Invert
On Inverts menu display and navigation
Off Turns off the display invert
Auto
Automatically inverts display when fixture mounting
is greater than 45°
Note: Unless you select
Off, you can adjust display
intensity level from 0 - 100%.
