APPENDIX D
DL.3 Specifications
DL.3 Digital Light User Manual 305
Environmental
Ambient Operating Temperature Range: 5°–40° C (40°–104° F)
Humidity: 20%–80% (non-condensing)
Altitude: 0–8850 ft (0–2700 m)
Camera Module
Construction: Super HAD CCD sensor technology
Lens: 18x Optical Zoom
Horizontal view angle: 48° –2.8°
Auto focus Range: 29 mm – 800 mm
Picture Elements: 380K pixels {768 (H) x 582 (V)}
Minimum working distance: 29 mm (WIDE end, 800 mm (TELE end)
Cables and Connectors
Video Connectors:
• SDI In and Out
• RGBHV—BNC x 5
• VGA—DB15
• S-Video—mini-DIN
Peripheral/Network Connectors:
• 2 USB ports
DMX and RS-485 Projector Link
Cables: Belden 9841 or equivalent (meets specifications for EIA RS-485 applications) with the
following characteristics:
• Two 4-conductor twisted pairs plus a shield
• Maximum capacitance between conductors: 30 pF/ft
• Maximum capacitance between conductor and shield: 55 pF/ft
• Maximum resistance: 20 Ohm/100 ft
• Nominal impedance: 100–140 Ohm
