CHAPTER 13
Effect Mode Options Descriptions
144 DL.3 Digital Light User Manual
Color Cycle
Effect Mode parameter DMX value = 14
The image’s color components cycle through RGB, black, and white. When no Red Green or Blue
is added, image fades from full white, to normal image, to black. When RGB/CMY is added the
image fades from the RGB value, to the image with color added.
Modifier 1: Increases red color component from 0 = no adjustment to 255 (100%) =
maximum red saturation.
Modifier 2: Increases green color component from 0 = no adjustment to
255 (100%) = maximum green saturation.
Modifier 3: Increases blue color component from 0 = no adjustment to 255
(100%) = maximum blue saturation.
Color DeConverge
Effect Mode parameter DMX value = 39
This effect option separates the different color components of an image and offsets them from
the original image position.
Modifier 1: Moves the image’s red component up from 0= no adjustment to 255 (100%) =
maximum distance from original position.
Modifier 2: Moves the image’s green component down and right from 0= no adjustment to 255
(100%) = maximum adjustment.
Modifier 3: Moves the image’s blue component down and left from 0 = no adjustment to 255
(100%) = maximum blue saturation.
Colorize Gray Scale
Effect Mode parameter DMX value = 44
This option maps a selected pixel intensity to a selected color scheme. A variety of color
schemes simulate effects like thermography. This is especially effective effect when applied to
input from the internal camera.
Modifier 1: Selects from color schemes along a range of values from 0 – 255.
Modifier 2: Sets the zero point of the color intensity level from 0 = no intensity to 255 (100%)
= maximum intensity.
Modifier 3: Fades from original color scheme to new color scheme using selected intensity.
Object Effect Global Effect
Object Effect Global Effect
Object Effect Global Effect
