Page 75
3 - 11
Note: This selection is unavailable when the Multiple Symbols Selection is
turned on.
Output Sequence Example
In this example, you are scanning Code 93, Code 128, and Code 39 barcodes,
but you want the image scanner to output Code 39 1st, Code 128 2nd, and Code
93 3rd, as shown below.
Note: Code 93 must be enabled to use this example.
You would set up the sequence editor with the following command line:
SEQBLK62999941FF6A999942FF69999943FF
The breakdown of the command line is shown below:
SEQBLKsequence editor start command
62
code identifier for Code 39
9999 code length that must match for Code 39, 9999 = all lengths
Required
On/Not Required
* Off
A - Code 39
B - Code 128
C - Code 93
