Page 62
2 - 16
Wand Emulation Idle
The idle describes the state of the image scanner when no data is being
transmitted. When in Wand Emulation mode, you must set the image scanner’s
idle state to match the idle state for the device to which the image scanner is
connected.
Default = Idle High
.
Wand Emulation Data Block Size
This transmits the data in smaller blocks to prevent buffer overflow.
Default = 40.
Wand Emulation Delay Between Blocks
This sets the delay time between data blocks.
Default = 50ms.
* Idle High
Idle Low
20
80
* 40
60
5ms
500ms
* 50ms
150ms
