B.2 Cable Kit
The cables are all 2m in length. Each set contains the cables listed below. Additional cable kit
and/or individual cables (in multiples of 10 each) are available from Elmo.
Cable Application
Cable Part. No.
QTY
Main Feedback
CBL-HDRFB-001 2
Auxiliary Feedback
CBL-HDRAUX-001
2
I/O
CBL-HDRIO-001
2
RS-232 Communications
CBL-RJ452321
1
CAN Communications
CBL-RJ45CAN1
1
Duo Installation Guide
MAN-DUO (Ver. 1.0)
B-2
