A.8 Mechanical Specifications
Feature Details
Mounting
The Duo designed for two standard
mounting options:
ƒ “Wall Mount” along the back (can
also be mounted horizontally on a
metal surface)
ƒ “Book Shelf” along the side
Overall dimensions 150 X 105 X 25.4 (5.9 X 4.13 X 1 in)
Weight ~ 450 grams
A.9 Environmental Conditions
Feature Details
Operating ambient temperature 0° to +40° C (32° to 40° F)
Storage temperature -20° to +85° C (-4° to 185° F)
Humidity 90% maximum non-condensing
Maximum Operating Altitude 10,000m (30,000 feet)
Protection level IP20
A.10 Compliance Standards
Specification Details
ISO9001 Quality Assurance
A.10.1 Design
Specification Details
MIL-HDBK- 217F Reliability prediction of electronic equipment
(rating, de-rating, stress and so on)
ƒ IPC-D-275
ƒ IPC-SM-782
ƒ IPC-CM-770
ƒ UL508c
ƒ UL840
Printed wiring for electronic equipment
(clearance, creepage, spacing, conductor
sizing and so on)
In compliance with VDE0160 -7 Type testing
Duo Installation Guide
MAN-DUOIG (Ver. 1.0)
A-15
