Duo Installation Guide

Introduction

MAN-DUOIG (Ver. 1.0)

2-2

2.2

Product Features

2.2.1 Current Control

ƒ

Fully digital

ƒ

Sinusoidal commutation with vector control or trapezoidal commutation
with encoder and/or digital Hall sensors

ƒ

12-bit current loop resolution

ƒ

Automatic gain scheduling, to compensate for variations in the DC bus
power supply

2.2.2 Velocity Control

ƒ

Fully digital

ƒ

Programmable PI and FFW (feed forward) control filters

ƒ

Sample rate two times current loop sample time

ƒ

“On-the-fly” gain scheduling

ƒ

Automatic, manual and advanced manual tuning and determination of
optimal gain and phase margins

2.2.3 Position Control

ƒ Programmable PIP control filter

ƒ Programmable notch and low-pass filters

ƒ Position follower mode for monitoring the motion of the slave axis relative

to a master axis, via an auxiliary encoder input

ƒ Pulse-and-direction input

s

ƒ

Sample rate four times current loop sample time

ƒ Fast event capturing inputs

2.2.4 Advanced Position Control (in Advanced model only)

ƒ

Position-based and time-based ECAM mode that supports a non-linear
follower mode, in which the motor tracks the master motion using an
ECAM table stored in flash memory

ƒ

PT and PVT motion modes

ƒ

Dual (position/velocity) loop

ƒ

Fast output compare (OC)

2.2.5 Communication Options

Depending on the application, Duo users can select from two communication
options:

ƒ

RS232 serial communication

ƒ

CANopen for fast communication in a multi-axis distributed environment

2.2.6 Feedback Options

• Incremental Encoder – up to 20 Mega-Counts (5 Mega-Pulse) per second
• Digital Halls – up to 2 KHz
• Incremental Encoder with Digital Halls for commutation – up to 20 Mega-

Counts per second for encoder
