EnGenius Technologies EOA7530 - Manual (Page 27)

Radio Click the radio button to enable or disable wireless functions.
Enable SSID# The EOA7530 supports four SSIDs. Each SSID can be configured to use a different
VLAN tag.
ESSID ESSID is the name of your wireless network (WLAN). In an area where more than one
WLAN is present, using a different ESSID allows you to separate the traffic. Any
device you want to participate in a particular WLAN must use the same ESSID. The
default ESSID is EnGenius. After specifying each ESSID, specify the VLAN ID for each
ESSID.
5G Wireless Settings
Band Select the IEEE 802.11 standard operating in your network environment.
Channel You should not need to change the wireless channel unless you notice interference
or are setting up the EOA7530 near another Access Point.
Data Rate Shows the available transmit data rate of the WLAN. The data rate affects
throughput. If you select a low data rate value, for example, the throughput is
reduced but the transmission distance increases.
Auto Channel By default, this option is disabled. If you click Enable, the EOA7530 searches all valid
channels, then decides which channel is “cleanest” for transmissions and change to
that channel automatically.
2.4G Wireless Settings
Band Select the IEEE 802.11 standard operating in your network environment.
26
